防蟻電纜FYH生產廠家，防鼠防蟻電纜
Rated voltage up to and including 35kV mouseproof or termiteproof powercable
產品標準 Standard
本產品按GB12706- 9《額定電壓35kv 及以下銅芯、鋁芯塑料絕緣電力電纜》、GB2951.38-86《電線電纜白蟻試驗方法》、Q/320282DCE014-2000《防鼠 電線電纜》標準生產。
電纜的型號 Type of cable 型號 Type 額定電壓 Rated voltage 名稱 Designation
銅芯 Copper conductor 鋁芯 Aluminum conductor
FSH-VV FSH-VLV 0.6/KV 聚氯乙烯絕緣聚氯乙烯護套防鼠電力電纜 PVC insulated , PVC sheathed mouseproof power cable
FSH-VV
FSH-VY FSH-VLY
FYH-VLY 聚氯乙烯絕緣聚乙烯護套防鼠電力電纜 PVC insulated , PE sheathed mouseproof power cable 聚氯乙烯絕緣聚乙烯護套防白蟻電力電纜 PVC insulated , PE sheathed temiteproof power cable
FSH-VV22 FSH-VLV22 聚氯乙烯絕緣鋼帶鎧裝聚氯乙烯護套防鼠電力電纜 PVC insulated ,steel tape armoured, PVC sheathed mouseproof power cable
FSH-VV23 FYH-VV23 FSH-VLV23 FYH-VLV23 聚氯乙烯絕緣鋼帶鎧裝聚乙烯護套防鼠電力電纜 PVC insulated, steel tape armoured ,PE shesthed mouseproof power cable 聚氯乙烯絕緣鋼帶鎧裝聚乙烯護套防白蟻電力電纜 PVC insulated, steel tape armoured ,PE sheathed termiteproof power cable
FSH-VV32 FSH-VLV32 聚氯乙烯絕緣細鋼絲鎧裝聚氯乙烯護套防鼠電力電纜 PVC insulated, steel wire armoured ,PVC sheathed mouseproof power cable
FSH-VV33 FYH-VV33 FSH-VLV33 FYH-VLV33 聚氯乙烯絕緣細鋼絲鎧裝聚乙烯護套防鼠電力電纜 PVC insulated, steel wire armoured ,PE sheathed mouseproof power cable 聚氯乙烯絕緣細鋼絲鎧裝聚乙烯護套防白蟻電力電纜 PVC insulated, steel wire armoured ,PE sheathed termiteproof power cable
FSH-YJV FSH-YJLV 6/1KV ~ 26/35KV 交聯聚乙烯絕緣聚氯乙烯護套防鼠電力電纜 XLPE insulated, PVC sheathed mouseproof power cable
FSH-YJV FYH-YJY FSH-YJLV FYH-YJLV 交聯聚乙烯絕緣聚乙烯護套防鼠電力電纜 XLPE insulated, el wire ,PE sheathed mouseproof power cable 交聯聚乙烯絕緣聚乙烯護套防白蟻電力電纜 XLPE insulated, steel wire ,PE sheathed termiteproof power cable
FSH-YJV22 FSH-YJLV22 交聯聚乙烯絕緣鋼帶鎧裝聚氯乙烯護套防鼠電力電纜 XLPE insulated, steel tape armoured ,PE sheathed mouseproof power cable
FSH-YJV23 FYH-YJV23 FSH-YJLV23 FYH-YJLV23 交聯聚乙烯絕緣鋼帶鎧裝聚乙烯護套防鼠電力電纜 XLPE insulated, steel tape armoured ,PE sheathed mouseproof power cable 交聯聚乙烯絕緣鋼帶鎧裝聚乙烯護套防白蟻電力電纜 XLPE insulated, steel tape armoured ,PE sheathed termiteproof power cable
FSH-YJV32 FSH-YJLV32 交聯聚乙烯絕緣細鋼絲鎧裝聚氯乙烯護套防鼠電力電纜 XLPE insulated, steel wire armoured ,PVC sheathed mouseproof power cable
FSH-YJV33 FYH-YJV33 FSH-YJV33 FYH-YJLV33 交聯聚乙烯絕緣細鋼絲鎧裝聚乙烯護套防鼠電力電纜 XLPE insulated, steel wire armoured ,PE sheathed mouseproof power cable 交聯聚乙烯絕緣細鋼絲鎧裝聚乙烯護套防白蟻電力電纜 XLPE insulated, steel wire armoured ,PE sheathed termiteproof power cable
防蟻電纜FYH生產廠家，防鼠防蟻電纜使用特性 Operating characteristics
·電纜導體的長期最高允許工作溫度：
Max.permissible continuous operating temperature of the conductor.
聚氯乙烯絕緣不超過70，交聯聚乙烯絕緣不超過90。
PVC insulated:70,XPLE insulated :90
·短路時(5秒內)最高溫度
Max.short-circuit temperature of the conductor (5s )
聚氯乙烯絕緣不能超過160，交聯聚乙烯絕緣不超過250。
·電纜敷設溫度不能低于0。
·The ambient temperature under installation should not below 0。
·電纜的彎曲半徑為：
·The bending radius of a cable 。
·單芯電纜不小于電纜外徑的20倍；多芯電纜不小于電纜外徑的15倍;
·single –core cables should not less than 20 times of the cable diameter , others not less than 15 times of the cable
·防鼠電纜經國家電線電纜質量監督檢驗中心及上海醫科大學動物試驗研究所試驗合格
具備國際同類產品的先進水平
Mouseproof cable is eligible ,because they have passed the mouseproof examination of national quality test center of wire and cable and animal experiment graduate school of university of medicinal science in Shanghai .
·防蟻電纜通過國標GB2951.38-86《電線電纜白蟻試驗方法》的檢驗。
Termiteproof power cable is passed through GB2951.38-86.
·采用先進的化學防鼠防白蟻方法，具有易加工、易施工、易維護、重量輕等優點。
Adopting advanced chemic way of ratproofing ,mouseproof or termiteproof cable have many virtue ,such as easy machining construction 、easy maintenance and light weight etc.
·具有低毒、無污染，不會對環境及人體造成二次災害。
They have lower wirulence and cannot bring pollution ,moreover cannot bring twice disaster to people and entironment.
·防鼠 防白蟻有效期長，可達二十年以上。
They have awfully longger period of validity on mouseproof or temiteproof hand, their period of validity are all of twenty years.
·可根據用戶要求生產具有耐火、阻燃特性的防鼠電線電纜。
Our company can product fire – retardant and flame – retardant wire and cable according to user requirement.
防蟻電纜FYH生產廠家，防鼠防蟻電纜生產范圍 型號 Type 額定電壓 KV Rated voltage 電纜芯數 No. of coers
1 2
3 4.3+1 5.3+2.4+1
